TENTEK TON-512100-L Battary, A sleek and space-saving solution for your energy storage needs. With its compact design and easy installation, whatever wall-mounted or floor standing, multi-install ways can meet different customers requirement. Even more the IP65 protection design, it seamlessly blends into any environment, whether in your home, office, or outdoor space, our unit provides reliable and efficient energy storage, empowering you to optimize energy usage and reduce waste.
TON-512100-L
● IP65 Protection: High standard design, for both indoor and outdoor installation.
● The Flexible Installation: Floor-standing and wall-mountable options
● Plug & Play Easy Extend: Simply put in the plugs and quickly paralleled up to 8 units.
● Wide Range of Applications: Compatible with 20+ storage inverters.
● The Shunt Trip Function: System will not shut down even if any abnormalities in parallel.
● Boasts a Long Life: Car grade LFP cells have longer lifespan and higher safety.
● The Modular Design: The BMS system runs independently when connected in parallel.
TON-512100-L TON-512100-S | |
Basic Parameter | |
Cell Type | LiFePo4 Semi Solid State LiFePo4 |
Nominal Capacity | 100Ah |
Nominal voltage | 51.2 V |
Energy | 5120Wh |
Charge Voltage | 58.4V |
Discharge Cut-off Voltage | 44..8V |
Charge Method | CC/CV |
Standard Charge Current | 50A |
Max. Charge Current | 100A |
Standard Discharge Current | 50A |
Max. Continues Discharge Current | 100A |
Cycle Life | ＞6000 |
Internal Impedance | ≤25mΩ |
Battery Charge/Discharge Voltage Protection | |
Pack OverCharge Alarm Voltage | 57.6V |
Pack Overcharge Protection Voltage | 58.4V |
Pack Overcharege Protection Time Delay | 1.0S |
Pack Discharge Alarm Voltage | 44.8V |
Pack Discharge Protection Voltage | 40V |
Pack Discharge Protection Time Delay | 1.0S |
Battery Charge/Discharge Current Protection | |
Over Chaege Alarm Current | 105A |
Over Charge Protection Current | 110A |
Over Charge Protection Time Delay | 1.0S |
Over Discharge Alarm Current | 105A |
Over Discharge Protection Current | 110A |
Over Discharge Protection Time Delay | 1.0S |
Battery Charge/Discharge Current Temperature Protection | |
Woring Temperature Range | Charge: 0℃～50℃；Discharge: -20℃～-50℃ |
Storage Temperature | -10℃～-50℃ |
Product Parameter | |
Dimensions(W*H*D) | L590*W470*H143.9 mm |
Output Wire | 6AWG |
Output Connector | TBD |
Communication | RS485/CAN |
Weight | 50kg |
Certification | IEC62619, UL1973, CE-EMC, CE-GPSD,EN61619; UN38.3, MSDS |
Pack Method | 1P16S |
